The machine was originally built in 1996. Originally overhauled by the manufacturer in 2011 for approximately €250,000: electrical and mechanical systems completely renewed. TECHNICAL DETAILS Pipe diameter: 16 - 60 mm Wall thickness: max. 3.0 mm Bending radius: 20 - 200 mm Pipe lifting length: 1,500 mm Bending angle: max. 180° + springback Pipe length: 400 - 1,500 mm Pipe outer diameter: 28 mm - 60 mm Material parameters Tensile strength of stainless steel: max. 750 N/mm² Tensile strength of mild steel: max. 450 N/mm² Performance limit (steel): Ø 60 x 3 mm Performance limit (stainless steel): Ø 57 x 2 mm Travel movements Bending direction: left Bending speed forward: max. 22.0 rpm (infinitely adjustable) Bending speed return: constant 22.0 1/min Rotation angle: max. 360° Twisting speed: 50 rpm Height adjustment multiple radii: lowest tube center 55 mm Height travel: suitable for 3-groove bending tools MACHINE DETAILS Follow-up time: 125 ms Machine weight: approx. 8.0 t Machine dimensions (L × W × H): 6,300 × 3,300 × 1,900 mm Control cabinet (L × W × H): 2,700 × 700 × 2,000 mm Control panel (L × W × H): 900 × 600 × 1,850 mm Tube magazine (L × W × H): 1,800 × 2,400 × 1,750 mm Operating hours: approx. 34,797 h Performance data Total power requirement: 55 kW Hydraulic filling volume: 340 l steering Bending levels: up to 6 (CNC programmable) Positioning device: NTB version Control unit: Schwarze-Robitec operating and control panel EQUIPMENT - Automatic pipe cold bending machine - Pipe positioning device - Gripper - Pipe magazine Schwarze-Robitec - Hydraulic operation for bending table, tool clamping, slide rail, mandrel retraction, reinforced slide rail feed and retraction - various bending tools for Ø 60 mm pipe - various aids - Cooling unit control cabinet - Foot control (2-way) - Schwarze-Robitec control panel - Cooling unit control cabinet Rittal type SK 3361100 Note: Due to a lack of operating knowledge, the machine could only be tested in setup mode. No errors are known.
₹10000 (binding)
